Fibaro Walli Controller

Parameters:

With parameters you can change things of the sensor itself, such as the update time and sensitivity of the motion sensor. Most controllers have this baked in by default. There is a wide range of settings available. I'm not going to cover all of these because this is covered extensively on the Fibaro website. I'll go through the main ones:

13.Light intensity LED
With this parameter you can set how light the LED should give.

Default value: 100
Available settings: 0 (off) - 100%

20.Operation mode
Default value: 0 (scene controller)
Available settings: 0 – scene controller, 1 – double button, 2 – single button, 3 – switch controller, 4- dimmer / roller shutter controller mode, 5 – roller shutter controller (step-by-step), 6 – Venetian blinds controller (step-by-step)

151. LED top button
With this parameter you can set which color should give when the top button is pressed.

Default setting:1 (White)
Available setting: 1 (White), 2 (Red). 3 (Green), 4 (Blue), 5 (Yellow), 6 (Cyan), 7 (Magenta), 8 (LAPD, blinking red, blue)

152. LED bottom button
With this parameter you can set which color should give when pressing the bottom button.

Default setting:1 (White)
Available setting: 1 (White), 2 (Red). 3 (Green), 4 (Blue), 5 (Yellow), 6 (Cyan), 7 (Magenta), 8 (LAPD, blinking red, blue)
