Neo Coolcam Motion Sensor (5in1)

Parameters:

With parameters you can change things of the sensor itself, such as the update time and sensitivity of the motion sensor. Most controllers have this baked in by default.

1. LED on/off
With this parameter you can switch the LED on/off.

Default value: 1
Available settings: 1 (On) 0 (Off)

2. PIR detection on/off
Allows you to enable/disable the PIR functionality

Default value: 1
Available settings: 0 (Off) or 1 (On)

3. Motion detection 1 time
With this you can have the PIR detected 1 time

Default value: 1
Available settings: 0 (1x) or 1(Always)

6. Sensitivity Level
With this parameter the sensitivity of the sensor can be set. The value 1 is the least sensitive and 4 the most sensitive.

Default value: 2
Available settings: 0 > 15 (15 = most sensitive)

7. Temperature offset
With the parameter you can correct the temperature measurement.

Default value: 0
Available settings: -120 > 120 (0.1 degrees)

8. Humidity Offset
With the parameter you can correct the humidity.

Default value: 0
Available settings: -120 - 120 (0.1 RH%)

10. Temperature change
This parameter determines at which temperature change from the previous value should be sent to the controller.

Default value: 10 (degrees)
Available settings: 0 > 120 (0.1 degrees)

11. Humidity change
This parameter determines at what change in humidity relative to the previous value should be sent to the controller.

Default value: 20 (RH%)
Available settings: 0 > 120 (0.1 RH%)

13. Motion blind time
The time when the motion detector sees nothing

Default value: 8
Available settings: 1 > 8 (sec)

15. Motion delete time
The time after movement that no movement is transmitted.

Default value: 30
Available settings: 1 > 30000 (sec)

17. Sensor interval
This parameter determines at which interval a value should be sent to the controller. Applies to all sensors.

Default value: 180 (LPM)
Available settings: 0 (all sensors off) - 30000 (sec)

18. Light sensor offset
With the parameter you can correct the light sensor.

Default value: 5320
Available settings: 1 > 32767
