Neo Coolcam Repeater

Parameters:

With parameters you can change things of the sensor itself, such as the update time and sensitivity of the motion sensor. Most controllers have this baked in by default.

1. Indicate LED status

With this parameter you can switch on or off that when a new value comes in, it lights up briefly.

Default value: 1
Available settings: 0 (off), 1 (on)

2) OTA LED

Default setting: 1
Available setting: 0 (no value), 1 (value)

3) Temperature offset

You can set how many degrees the measured temperature should deviate.

Default setting: 0
Available setting: -120 > 120 (value x 0.1 degrees)

4) Humidity offset

You can set how much RH% the measured humidity should deviate.

Default setting: 0
Available setting: -120 > 120 (value x 0.1 RH%)

5) Deviation value of temperature

With this you can set at how much difference (compared to the previous value) in temperature an update should be sent to the controller.

Default setting: 10
Available setting: 0 > 100 (value x 0.1 degrees)

6) Deviation value of humidity

With this you can set at how much difference (compared to the previous value) in humidity an update should be sent to the controller.

Default setting: 10
Available setting: 0 > 100 (value x 0.1 RH%)

7) Low temperature alarm

Default setting: 180
Available setting: -200 to 600 (value x 0.1 degrees)

8) High temperature alarm

Default setting: 300
Available setting: -200 to 600 (value x 0.1 degrees)

9) Low Humidity Alarm

Default setting: 400
Available setting: 200 to 850 (value x 0.1 RH%)

10) High Humidity Alarm

Default setting: 400
Available setting: 200 to 850 (value x 0.1 RH%)

11) Sensor interval

Default setting: 300
Available setting: 0 > 30000 (higher is slower)

12) Heartbeat interval

With this value you can set the interval at which a new value is sent to the controller. If you set this value it will ignore parameters 5 and 6.

Default setting: 3600
Available setting: 0 > 30000
